7 - 79

7 Digital I/O Slave Unit

GX-series EtherCAT Slave Unit User’s Manual

7-5 Mounting Dimensions

7

7-5-3 e-CON Connector Type

 GX-MD3218/MD3228

3.14

52

180

50

49.8

(mm)
