The IO-Link Master Unit has the following types of output data. You can allocate the required data in the
OUT area.
*1 Unit version 1.0 : No
Unit version 1.1 or later : Yes
The following data is allocated for the default settings.
• Unit version 1.0
• Unit version 1.1 or later
10-2-2 Allocating Output Data
Data name Size
Default I/O
allocation
Details
Digital Output Data 2 bytes
*1
This is the digital output data in SIO(DO) Mode.
Port 1 IO-Link Process
Output Data
32 words × 8
ports
Yes (2 bytes per
port)
This is the output data from IO-Link devices such as
actuators that are connected to port 1 in IO-Link Mode.
·
·
·
·
·
·
Port 8 IO-Link Process
Output Data
This is the output data from IO-Link devices such as
actuators that are connected to port 8 in IO-Link Mode.
Output offset
(words)
D15 D14 D13 D12 D11 D10 D09 D08 D07 D06 D05 D04 D03 D02 D01 D00
0 Port 1 IO-Link Process Output Data 01 Upper Byte Port 1 IO-Link Process Output Data 01 Lower Byte
+1 Port 2 IO-Link Process Output Data 01 Upper Byte Port 2 IO-Link Process Output Data 01 Lower Byte
·
·
·
·
·
·
·
·
·
+7 Port 8 IO-Link Process Output Data 01 Upper Byte Port 8 IO-Link Process Output Data 01 Lower Byte
Output offset
(words)
D15 D14 D13 D12 D11 D10 D09 D08 D07 D06 D05 D04 D03 D02 D01 D00
0 Digital Output Data Upper Byte Digital Output Data Lower Byte
+1 Port 1 IO-Link Process Output Data 01 Upper Byte Port 1 IO-Link Process Output Data 01 Lower Byte
·
·
·
·
·
·
·
·
·
+7 Port 7 IO-Link Process Output Data 01 Upper Byte Port 7 IO-Link Process Output Data 01 Lower Byte
+8 Port 8 IO-Link Process Output Data 01 Upper Byte Port 8 IO-Link Process Output Data 01 Lower Byte
