A
Appendix
A - 78
GX-series EtherCA
T Slave Unit User
’s Manual
A-4
W
iring External Output Signal Lines
Observe the following points when wiring external
output signal lines.
•
T
o absorb reverse electromotive force when an inductive load is connected to an output signa
l,
connect a diode near the inductive loa
d.
Connect a diode in a DC circuit.
Output Signal Noise Countermeasure
Output
transistor
Output Unit
(with output transistor)
Diode
Inductive
load
381
383
