9 Encoder Input Slave Unit

9 - 30

GX-series EtherCAT Slave Unit User’s Manual

9-5 Mounting Dimensions

The mounting dimensions of an Encoder Input Slave Unit are shown below.

93.5

10.1

68.9

52

3.14 50

215

[mm]
