8 Analog I/O Slave Unit

GX-series EtherCAT Slave Unit User’s Manual

8-7 Mounting Dimensions

8

8-7 Mounting Dimensions

The mounting dimensions of an Analog I/O Slave Unit are shown below.

73.9

50

135

52

3.14

57.1

(mm)
