10 IO-Link Master Unit
10 - 10
GX-series EtherCAT Slave Unit User’s Manual
General Specifications
The following table gives the general specifications of the GX-ILM08C.
*1 Confirms to Class A when used as an IO-Link connector.
*2 For SmartClick Connectors, insert the Connector all the way and turn it approx. 1/8 of a turn. Torque
management is not required.
Item Specification
Unit power supply
voltage
20.4 to 26.4 VDC (24 VDC −15%/+10%)
I/O power supply 20.4 to 26.4 VDC (24 VDC −15%/+10%)
Noise resistance Conforms to IEC 61000-4-4, 2 kV (power line).
Vibration resistance
Malfunction: 10 to 60 Hz with amplitude of 0.7 mm, 60 to 150 Hz and 50 m/s
2
for 80
minutes each in X, Y, and Z directions
Shock resistance
150 m/s
2
with amplitude of 0.7 mm
Dielectric strength 600 VAC (between isolated circuits)
Insulation resistance 20 MΩ min. (between isolated circuits)
Ambient operating
temperature
−10 to 55°C
Ambient operating
humidity
25% to 85% (with no condensation)
Ambient operating
atmosphere
No corrosive gases
Altitude 2,000 m max.
Storage temperature −25 to 65°C
Storage humidity 25% to 85% (with no condensation)
Degree of protection IP67
Mounting M5 screw mounting
Mounting strength 100 N
Communications
connector strength
30 N
Connector types
Connectors for EtherCAT communications: M12 (D-coding, female) × 2
Power supply connector: M12 (A-coding, male) × 1
I/O connectors: M12 (A-coding, female)
*1
× 8
Screw tightening
torque
*2
Round connectors (communications connector, power supply, and I/O): 0.39 to 0.49
N·m
M5 (Unit mounted from the front):1.47 to 1.96 N·m
Cover for node address setting switches: 0.4 to 0.6 N·m
Applicable standards EU: EN 61131-2, RCM, KC, cULus, and IO-Link conformance
