Omron GX-ID1611

A - 73
A Appendix
GX-series EtherCAT Slave Unit User’s Manual
A-1 Object Dictionary
A
A-1-7 Manufacturer Specific Objects
A020 hex Port3 IO-Link Master Object
Sub-index 0: Number of entries
Range: − Unit: − Default: 01 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Port3 Lost Frames
Range: 00 to FF hex Unit: − Default: 00 hex Attribute: A
Size: 1 byte (U8) Access: RW PDO map: Not possible
A030 hex Port4 IO-Link Master Object
Sub-index 0: Number of entries
Range: − Unit: − Default: 01 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Port4 Lost Frames
Range: 00 to FF hex Unit: − Default: 00 hex Attribute: A
Size: 1 byte (U8) Access: RW PDO map: Not possible
A040 hex Port5 IO-Link Master Object
Sub-index 0: Number of entries
Range: − Unit: − Default: 01 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Port5 Lost Frames
Range: 00 to FF hex Unit: − Default: 00 hex Attribute: A
Size: 1 byte (U8) Access: RW PDO map: Not possible
A050 hex Port6 IO-Link Master Object
Sub-index 0: Number of entries
Range: − Unit: − Default: 01 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Port6 Lost Frames
Range: 00 to FF hex Unit: − Default: 00 hex Attribute: A
Size: 1 byte (U8) Access: RW PDO map: Not possible
A060 hex Port7 IO-Link Master Object
Sub-index 0: Number of entries
Range: − Unit: − Default: 01 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Port7 Lost Frames
Range: 00 to FF hex Unit: − Default: 00 hex Attribute: A
Size: 1 byte (U8) Access: RW PDO map: Not possible
A070 hex Port8 IO-Link Master Object
Sub-index 0: Number of entries
Range: − Unit: − Default: 01 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Port8 Lost Frames
Range: 00 to FF hex Unit: − Default: 00 hex Attribute: A
Size: 1 byte (U8) Access: RW PDO map: Not possible
