3-203
3 Functions of NB-Designer
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
3-7 Function Parts
3
3-7-2 Function Key
Example: Create Unicode keyboard by the combination of Text Input and Function Key.
The Unicode keyboard can be created by using [Unicode] option, which is available in the
related Property screen of Text Display component, Text Input component and Note Book
component, in combination with the [Key Button] - [Unicode] option in the Function Key
Property.
(1) Make the following settings after adding two Text Input components.
(2) Add the Function Key and set the character to be input.
(3) Add one [Enter] key, i.e. select “[Key Button] - [Enter]” in the “Key Button” tab.
(4) The final effect is as shown below.
Unicode function currently only supports Chinese, English, Japanese and the common
symbols.
Properties Text Input A Text Input B
Unicode Unicode Unicode
Address LW0 LW3
Word Length 3 3
