3-43
3 Functions of NB-Designer
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
3-3 NB-Designer Software Window
3
3-3-4 Output Window
The Output Window mainly displays compilation information of the project so that the user can precisely
pinpoint where errors lie, as shown below.
When the project is opened, the Output Window will display the loaded information of the project. when
the project is compiled, the Output Window will display the compilation process and error information.
Clearance/Export of Message
The compiled information can be cleared or exported in the Output Window. Right-click the mouse in
the [Output Window], the following menu will pop up.
Clear Message: All the information in the Output Window will be removed.
Export Message: All the contents in the Output Window are exported to the folder which contains
the current project, forming a file named “log.txt”.
3-3-4 Output Window
