4-11
4 Functions of NBManager
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
4-3 Upload Operation
4
4-3 Upload Operation
Upload Operate is mainly used for the file upload from PT to PC.
The communication parameters must be set before the upload.
The Communication Setting is same as that of download.
Select Data:
Upload Project Files:
Enter descriptions to [PT Information], if necessary.
Firstly check [Project Data (required)] and click the [OK] button to select the path for saving the data,
then click the [Save] button after inputting the file name.
After the [Password(Upload)] pops up, input 888888 and press the OK button to perform the upload.
Note The default password for upload is 888888.
If you want to modify the upload password, please double-click the PT in Project Work Space and
modify [Password] corresponding to “Allow Upload” in [PT Extended Properties] tab.
