7-9
7 PictBridge Printing
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
7-5 List of Error Codes for Printing
7
7-5 List of Error Codes for Printing
When the printing has some problems, error will occur in the system with the error codes displayed.
The error codes displayed include the following codes. The error codes will be displayed the PT screen
and stored in the system memory (lower words) and LW9801 (higher words).
Codes (Value) Description
0x73000000 Normal status (default).
0x7300FFF9 Printer not ready
0x7300FFFA Printer busy (Trigger another print job when printer is printing)
0x7300FFFB Driver & UI Printer Settings Disable
0x7300FFFC UI Printer Setting Disable
0x7300FFFD USB Cable not Connect
0x7300FFFE Others Reason
0x7300FFFF Driver is not configured
0x73010000 Paper related error (default).
0x73010100 Paper is empty.
0x73010200 Load Error - paper not loaded correctly.
0x73010300 Eject Error - paper not ejected correctly.
0x73010400 Media Error - paper not detected, paper skewed, roll paper cannot be cut or torn-off.
0x73010500 Paper jam.
0x73010600 Paper nearly empty.
0x73010700 The combination of paper type and paper size is not supported, or paper set in Printer does
not match request.
0x73020000 Ink related reason (default).
0x73020100 Ink empty.
0x73020200 Ink low.
0x73020300 Waste ink error (waste-ink reservoir full).
0x73030000 Hardware-related error. (default)
0x73030100 Fatal error.
0x73030200 Service call.
0x73030300 Printer unavailable (performing maintenance or processing jobs).
0x73030400 Printer buffer memory full.
0x73030500 Lever error (lever position not correct).
0x73030600 Cover open.
0x73030700 No print unit (e.g., missing print head).
0x73030800 Ink Cover open.
0x73030900 No ink Cartridge.
0x73040000 File-related error. (default)
0x73040100
Printinfo error (the size of inf
or
mation set to <Pri
ntinfo> is
too large.)
0x73040200 File decode error (picture format of specified image cannot be decoded).
To Next Page
