8 Web Interface
8-4
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
8-3 Connection Method and Each Page
Function
In order to access the NB Unit with the use of the Web browser, access http://[the NB Unit IP address]/. Initial
display of screen may be changed according to setting. However, Menu page is displayed in factory setting.
• Menu page
It is a page displayed by default at the time of shipment. Through this page, it is accessible to each page.
*1: Kernel 1764 or RootFS 2102 or higher is required.
• Monitoring page
It is a page to refer to the screen which is currently displayed on the NB Unit. A screen is updated at the inter-
val according to the setting. The screen displayed is not available to be operated with the monitoring page.
Function Name Details
Monitor It displays a monitoring page.
Operation It displays an operation page.
Files in
USB Disk
*1
It displays a file list in the USB Disk that mounts to the NB
Unit. Displaying the file contents and downloading the file
are available on Web browser.
Configuration It displays a configuration page.
To Next Page
