3-10 System Parameters
3
3-10 System Parameters
Specifications related to the NB units are performed in the PT Property.
The PT Property can specify the procedure to display the PT screens and the system specifications of
the PT units as well as the communications settings.
Double-clicking PT in Configuration and Setup Window can make system parameter dialog box pop up.
There are 11 tabs related to the communication: [PT], [Task Bar], [PT Extended Properties], [System
Information Setting], [User Permission Setting], [Security Level Setting], [Event History Setting], [Print
Setting], [COM1 Setting], [COM2 Setting], and [External Memory]. They will be described in the later
one by one.
