3 Functions of NB-Designer
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
3-5 Basic Design Method
3
3-5-2 About ID No.
ID No. is the number automatically assigned to the component for differentiating the components on the
PT. The designer cannot change component ID number artificially.
The contents represented by ID No. are as follows:
Parts:
SB: Bit Button
BL: Bit Lamp
SW: Bit Switch
DW: Direct Screen
SWD: Command Button
WL: Word Lamp
MSW: Word Switch
SCR: Scroll Bar
MV: Moving Component
ANI: Animation
AD: Alarm
TR: Data Log
XY: XY Graph
BR: Level Meter
MT: Analog Meter
RCP: Recipe
ED: Event
IDW: Indirect Screen
ND: Number Display
TD: Text Display
NI: Number Input
TI: Text Input
OS: Oscillograph
NB: Note Book
NL: Word Neon Lamp
BNL: Bit Neon Lamp
TT: Touch Trigger
GR: Table
HDD: Data History
3-5-2 About ID No.
BL: Bit
Lamp
BL0 0: Component No,
