3-265

3 Functions of NB-Designer

NB-series Programmable Terminals NB-Designer Operation Manual(V106)

3-9 Macro Function

3-9-1 Create a Simple Macro Program

After editing the Macro in the procedure as the above, perform the test again. Then the result as follows

should be out.

Now the basic specification is completed. However, the Macro still have a problem. When entering “0”

into LW1 and executing the Macro, an error occurs and the error can affect the normal operation of the

system. In this case, a check should be entered into the operand.

Change the codes shown as below.

int MacroEntry()

{

//Judge whether LW1 is 0 or not in order to prevent “Divide-by-zero overflow” ;

if (LW1_R!=0)

//LW0 divides LW1and LW2 is obtained

LW2_W = (double)(LW0_R)/LW1_R;

return 0;

}

Execute it again. If the divisor is 0, the Macro will not execute division. Therefore, the program safety

will be improved.
