Omron NB-series User Manual

3 Functions of NB-Designer
3-326
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
9152~9167 Display Pinyin character input currently
when using Pinyin
(Read)
9170 Page up/down of Note Book component The value of this LW means the start line of input area.
9180~9187 Text display of maximum value of
Number Input
(Read)
9190~9197 Text display of minimum value of Number
Input
(Read)
9200~9205 Time value of browsing point of Data Log These six words are used to display second, minute,
hour, day, month and year respectively in BIN code
(read).
9210 Display values of each channel during
referencing
The current value of each channel is displayed one by
one according to the bit width of the browsed Data Log
(read).
9260~9261 Start address for RW clearing operation Sets the start address for RW clearing operation
triggered by LB9130 (read/write).
9262~9263 Word length of RW clearing operation Sets the word length for RW clearing operation
triggered by LB9130 (read/write).
9264~9279 Mask code of PLC Station No.(COM 2) Each bit corresponds to one Station No. of COM 2 (i.e.
9264.0 corresponds to Station No. 0... and 9279.F
corresponds to Station No. 255). When the bit is turned
ON, the communication corresponding to Station No.
will be stopped (read/write).
9296~9299 Mask code of error information Each bit corresponds to one piece of error information.
When the bit is turned ON, the corresponding prompt
error information will not be displayed. Refer to 3-11-4
System Information Table (Page 3-329) in NBDesigner
Operation Manual for details. (read/write).
9300 Name of path referred by File List
component
The name of path currently referred (32 words) by the
File List Component will be specified.
9332 Name of file selected by File List
component
The name of file selected (32 words) by the File List
Component will be specified.
9364 Setting Import and Export Specify the Import and Export of the project and the
Recipe (read/write).
9366 Description of processing File Browsing
Component
“1” indicates Copy, “2” does Cut, and “3” does Paste,
respectively (write).
9370 Confirm Operation method Confirm Operation method: 1: Confirm; 2: Cancel
(write).
9380~9395 History value of Number Input
component
Specify the data set before the input operation (read).
9416~9431 Index memory for Station No. variable Each word corresponds to the index (0~15) for Station
No. variable (read/write).
9432~9447 memory for indicating communication
state (COM 2)
Each bit corresponds to one Station No. (9432.0
corresponds to 0,
..., and 9447.F corresponds to 255).
The relevant bit is set to ON when PLC is under time-
out condition and has no response, otherwise it will be
set to OFF (read).
9465 Time-out ratio of Macro Specify the maximum time allocating to the execution
of a Macro. The time multiplying the default value, 200
ms with the specified value will be the maximum time
(read/write).
9470 File name of the screen shot The prefix text string of 16 words naming the screen
shot which is stored in USB memory.
9486~9501 User name Inputs the login user name of up to 32 characters
(read/write).
9502~9503 User password Inputs the password corresponding to the login user
(read/write).
9504~9505 Current user permission Displays 32 authorities corresponding to current login
users (read).
