3 Functions of NB-Designer
3-328
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
Others:
The following addresses will be valid after the restart. They are retained even if power failure occurs in
readable or writable addresses.
Note If the address exceeds 10,000, the address cannot be modified during simulation. But the read operation is
available (For example, the Number Input component with the address of LW10005 will be displayed as 2006
during the test, and it can’t be modified to the other value during the test. But it can be modified only after it
is downloaded to the PT. ).
System parameter settings
Addresses Descriptions Comments
10010 No. of Initial Screen It ranges from 0 to 32767.
10011 Screen saver (Backlight) 0 (Disable Screen saver)
1 to 600 minutes (enabled)
10012 Buzzer 0: Disabled, 1: Enabled
10013 Common Sheet/Pop-up Screen 0: Normal, 1: At the top of all the other screens
10014 Placing Common Sheet
0: At the bottom of Base Screen, 1: At the top of Base Screen
10015 Number of stored events It ranges from 0 to 65535. If it is set to “0”, the event
data will be cleared after the restart.
10016 Source of RTC 0: PLC (LW), 1: Internal RTC.
10017 Default language It ranges from 0 to 3.
10018 Reserved by system
Security level
Addresses Descriptions Comments
10022~
10023
Password/0 Double-word is occupied.
10024~
10025
Password/1 Double-word is occupied.
10026~
10027
Password/2 Double-word is occupied.
10118~
10143
Password/3 to 15 Double-word is occupied × 13.
Initial Communications Parameters
Addresses Descriptions Comments
10030~
10033
IP Address of the NB Units If it is changed, restart is needed
i.e. IP Address: 192.168.250.1
LW10030:1,
LW10031:250,
LW10032:168,
LW10033:192
10034 Port Number of the NB Unit If it is changed, restart is needed
10035 Reserved by system
10036 COM 2 operation mode 0: RS-232, 1: RS-422, 2: RS-485.
10037~
10038
COM 2 Baud Rate Double-word.
10039 COM 2 Data Bit
10040 COM 2 Parity Bit
10041 COM 2 Stop Bit
10042 COM 2 Station No. (PT Station No.)
10043~
10044
COM 2 PLC timeout duration
10045~
10046
COM 2 Protocol Time Out 1
10047~
10048
COM 2 Protocol Time Out 2
