6-3 Component Improvement
6
6-3-2 Event, Event History Display and Event Display
Descriptions of Table Display Properties
Display Item Time Checking it means the event occurred time, checked time and
canceled time will be displayed and the time format can be selected
There are 3 formats available, and HH, MM, SS and MS refer to the
hour, minute, second and millisecond respectively.
Date Checking it means the event occurred date, checked date and
canceled date will be displayed and the date format can be selected
among three formats such as DD*MM*YY, MM*DD*YY, and
YY*MM*DD, and YY, MM and DD refer to the year, month and date
respectively.
Date Separator Three characters of delimiter(/,-,.) are available. i.e. 11/06/24.
Sequence Number Checking it the sequence number of each event information will be
displayed.
Ascending When it is checked, the event information will be displayed in the
ascending order, i.e. the latest event will be displayed on the bottom.
When it is not checked, the event information will be displayed in the
descending order, i.e. the latest event will be displayed on the top.
Background
Color
Sets the Background Color, Title Bar Background Color, Frame Color and Frame Width for the
Event History Display component table.
Event History
Query
Query by File Name When it is checked, the value of specified memory being 0 means to
call out today’s or the latest event history information, and the value of
specified memory being 1 means to call out the event history
information stored on the previous day and so on. [For example] With
two event history information files 20110621.csv and 20110624.csv
stored in the external memory, when the value of specified memory is
0, the event history information stored on June 24th, 2011 can be
called out, while the event history information stored on June 21th,
2011 can be called out and displayed when the value of specified
memory is 1.
Query by Date When it is checked, the date will be input into the specified memory
and the event history information corresponding to the date will be
called out. The date format is yyyymmdd (Where, yyyy, mm and dd
refer to the year, month and date respectively.) [For example] Inputting
20110624 into the specified memory can call out and display the event
history information saved on June 24th, 2011.
Border Setting Border Color, Style and Width for each row or each column and the Row Spacing and Column
Spacing with the unit of pixel point. Checking “Horizontal Line” means the separator will be
displayed horizontally, and checking “Vertical Line” means the separator will be displayed
vertically.
Status display Occurring Display the information indicates that the event is occurring in the
status column. Although it is set to “0” by default, it can be modified.
Checked Display the information indicates that the event is checked in the status
column. Although it is set to “1” by default, it can be modified.
Canceled Display the information indicates that the event is canceled in the
status column. Although it is set to “2” by default, it can be modified.
Title Bar Setting Sets the Name and Font displayed in Title Bar of the table.
