6-23
6 Descriptions of New Functions Added into NB-TW01B
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
6-3 Component Improvement
6
6-3-4 Operation Log
• Settings for related Properties of Operation Log component
Storage of Operation Log
When the Operation Log component is used, the path for storing the log file should be set in the
[Operation Log Storage Setting] option in the [PT Extended Properties] tab in the [PT Property] dia-
log box.
For the output file in CSV format, if the [Daily File] is selected, the file storage path is “log/subfolder
name/yyyymmdd.csv”, and if the [Single File] is selected, the storage path is “log/subfolder
name/subfolder name.csv”. (Where, yyyymmdd is the created date of the operational records. For
example: 20110101)
Settings of the components for Operation Log
For the component with the requirement of displaying the Operation Log in the Operation Log, it
needs to check the [Operation Log] option in the [Security Setting] part in the [Control Setting] tab in
the property dialog box of the component on which should be operated.
Saving the related information into the external memory:
The related information can be stored in the external memory by using the “Operation Log Storage
Setting” option in the [PT Extended Properties] tab in the [PT Property] dialog box, as shown below.
To Next Page
