7 PictBridge Printing
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
7-3 Components Related to Printing and Setup Descriptions
7
7-3-1 PLC Control
Custom Print Options Properties Description:
* Default Magnification (based on standard A4 paper):
Method 2: Don't check Custom Print Options, and make the setting through the corresponding bits
of the system memories LW9054 and LW9055.
The value of LW9054 can be set with the Command Button component. If all contents on the PT
screen are to be printed, place the Command Button component to the Common Sheet. Select [Set
value when screen is loading] in the [Command Button] tab of the [Command Button Property],
specify [Set Value] to “255”, and specify LW9054 to a value allow all the content printed.
[Example] To print the content in the current page with a magnification of 0.3 in monochrome, set
LW.B9055.0, LW.B9055.1 and LW.B9055.8 all ON, and LW.B9055.9 OFF; or set LW9055 to “259”.
Custom Print Options Properties Details
Printer Color Black and White Only color printers support printer color change.
Color
Black and White
(Reverse Color)
Prints the monochrome in reverse color.
Magnification It can be selected from 0.1 to 5.0 (Zoom Out printing may cause distortion, thus is not
recommended.)*
Print Page Current Page Print the current screen.
Landscape print the content with landscape orientation.
Portrait print the content with portrait orientation.
Print Content Print Text
Prints the static texts and label characters on the current
screen.
Print Analog Meter Prints the Analog Meter components on the current screen.
Print Trend Graph Prints the Trend Graph on the current screen.
Print All Bitmap Prints all the Bitmaps on the current screen.
Print All The Vector Map Prints all the Vector Graphics on the current screen.
Print Background Colors Prints the background color of the current screen.
PT Model
NB3Q/NB5Q -TWB NB7W/NB10W-TWB
Print Direction Landscape Portrait Landscape Portrait
Display
Mode
Horizontal Display 4321.4
Vertical Display 341.42
Lw9054 Settings
Bit No. Name 0 (The bit is OFF) 1 (The bit is ON)
Bit 0 Print Text Not print Print
Bit 1 Print Analog Meter Not print Print
Bit 2 Print Trend Graph Not print Print
Bit 3 Print All Bitmap Not print Print
Bit 4 Print All The Vector Map Not print Print
Bit 5 Print Background Colors Not print Print
Lw9055 Settings
Bit No. Name 0 (The bit is OFF) 1 (The bit is ON)
Bit 0~ Bit 7 Magnification Ranges from 1 to 50 with the meaning of magnifying
0.1 to 5.0 times respectively.
Bit 8 Printer Color Color Black and White
Bit 9 Print Page Prints the current page System Reserved
Bit 10 Print Direction Landscape Portrait
Bit 12 Reverse Color Print Normal Print Reverse Color Print
