NB-series Programmable Terminals NB-Designer Operation Manual(V106)
A-1 List of Models
App
 Units at the host side which can be connected using the serial port of the NB
Unit in the RS-232C mode through Host Link
*1: Connect using conversion cables (CPM2C-CN111 type or CS1W-CN114/118 type), the RS-232C adaptor
(CPM1-CIF01 type) or the RS-422A adaptor (CPM1-CIF11 type).
*2: The CQM1H-CPU11 model does not have the RS-232C port built in the CPU, therefore it requires a peripheral
port to be connected to a PT through a conversion cable (CS1W-CN118 type).
PLC
Series
CPU Unit with built-in Host
Link function
Through Serial Communication
units/boards
Options required for
connection
CP Series CP1L-L14/L20/M30/M40/M60 CP1W-CIF01
CP1H-X40/XA40/Y20 CP1W-CIF01
CP1E-N14/N20
CP1E-N30/N40/N60/NA20 CP1E-N30/N40/N60/NA20 CP1W-CIF01
CP1L-EL20/EM30/EM40 CP1W-CIF01
C Series C200HE-CPU42
C200HE-CPU42-Z
C200HE-CPU32/42
C200HE-CPU32/42-Z
C200HW-
COM02/04/05/06-V1
C200HG-CPU43/63
C200HG-CPU43/63-Z
C200HG-CPU33/43/53/63
C200HG-CPU33/43/53/63-Z
C200HW-
COM02/04/05/06-V1
C200HX-CPU44/64
C200HX-CPU44/64/65/85-Z
C200HX-CPU34/44/54/64
C200HX-CPU34/44/54/64/65/85-Z
C200HW-
COM02/04/05/06-V1
CPM1-10/20CDR-
+CPM1-CIF01
CPM1A-10/20/30/40CD-
+CPM1-CIF01
CPM2A-30/40/60CD-
+CPM1-CIF01
(When a peripheral port is
connected)
CPM2C-10/20-
(*1)
CQM1H-CPU11/21/51/61 (*2) CQM1H-CPU51/61 CQM1H-SCB41
CS Series CS1G-CPU42/43/44/45 (-V1)
CS1H-CPU63/64/65/66/67 (-V1)
CS1G-CPU42/43/44/45 (-V1)
CS1H-CPU63/64/65/66/67 (-V1)
CS1W-SCU21 (-V1)
CS1W-SCB21/41 (-V1)
CS1G-CPU42H/43H/44H/45H
CS1H-
CPU63H/64H/65H/66H/67H
CS1G-CPU42H/43H/44H/45H
CS1H-CPU63H/64H/65H/66H/67H
CS1W-SCU21 (-V1)
CS1W-SCB21/41 (-V1)
CJ Series CJ1G-CPU44/CPU45 CJ1G-CPU44/CPU45 CJ1W-SCU21/41/-V1
CJ1G-CPU42H/43H/44H/45H
CJ1H-CPU65H/66H/67H
CJ1G-CPU42H/43H/44H/45H
CJ1H-CPU65H/66H/67H
CJ1W-SCU21/41/-V1
CJ1M-CPU11/12/13/21/22/23 CJ1M-CPU11/12/13/21/22/23 CJ1W-SCU21/41/-V1
CJ2M-CPU31/32/33/34/35 CP1W-CIF01
CJ2M-CPU11/12/13/14/15
CJ2H-CPU64/65/66/67/68(-EIP)
