A-5
Appendices
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
A-1 List of Models
App
Units at the host side which can be connected using the Ethernet port of the
NB Unit
NB-Designer version information
Related connecting objects
Cable with connectors (NB Unit ↔ PLC)
PLC Series
CPU Unit with built-in Ethernet
communication function
Through Ethernet Unit/Option boards
Options
required for
connection
CP Series CP1L-L14/L20/M30/M40/M60 CP1W-CIF41
CP1H-X40/XA40/Y20 CP1W-CIF41
CP1E-N30/N40/N60/NA20 CP1W-CIF41
CP1L-EL20/EM30/EM40
CS Series CS1G-CPU42/43/44/45(-V1)
CS1H-CPU63/64/65/66/67(-V1)
CS1W-ETN21
CS1W-EIP21
CS1G-CPU42H/43H/44H/45H
CS1H-CPU63H/64H/65H/66H/67H
CS1W-ETN21
CS1W-EIP21
CS1H-CPU63/64/65/66/67 (-V1) CS1W-ETN21
CS1W-EIP21
CS1H-CPU63H/64H/65H/66H/67H CS1W-ETN21
CS1W-EIP21
CJ Series CJ1G-CPU42H/43H/44H/45H
CJ1H-CPU65H/CPU66H
CJ1W-ETN21
CJ1W-EIP21
CJ1M-CPU11/12/13/21/22/23 CJ1W-ETN21
CJ1W-EIP21
CJ1H-CPU65H-R/66H-R/67H-R
CJ1H-CPU65H/CPU66H
CJ1W-ETN21
CJ1W-EIP21
CJ2M-CPU31/32/33/34/35
CJ2M-CPU11/12/13/14/15 CJ1W-ETN21
CJ1W-EIP21
CJ2H-CPU64/65/66/67/68(-EIP)
NJ Series NJ501/301
Version Release Time Descriptions Remarks
V1.0X February 2012 PT with model number of NB5Q-TW00B
and NB7W-TW00B supported
OS: Windows XP (SP3 or higher)
Windows Vista/Windows 7/8 (32/64-
bit) The NB-Designer incorporates a
transmission program and a standard
system program specified for the NB-
Series Units. For download the
application programs, please access
your local Omron website, If local site
cannot be found, please access
Omron IA global site
“http://www.ia.omron.com/ ”at first and
select the area where you are.
V1.1X June 2012 PT with model number of NB5Q-TW01B
and NB7W-TW01B added
V1.20 August 2012
PT with model number of NB3Q-TW00B/
TW01B and NB10W-TW01B added
AB/GC PLC supported
English version added
V1.21 October 2012 Besides English and Simplified Chinese,
7 languages supported (Traditional
Chinese, Korean, Spanish, Italian,
Portuguese, Turkish and Russian)
V1.22 December 2012 PictBridge printing supported
Japanese version added
V1.23 December 2012 OMRON PLC serial port communication
protocol optimized
The compatibility of the firmware upgrade
improved
Models Cable Length Object Unit Communications methods Specifications
XW2Z-200T 2m Units with 9-pin connectors
by OMRON
Host Link
(RS-232C)
9-pin ↔9-pin
XW2Z-500T 5m
NB-RSEXT-2M 2m RS-422/485
Communication Units by
PLC manufactures
Host Link
(RS-422)
9-pin ↔5 wire
To Next Page
