NB-series Programmable Terminals NB-Designer Operation Manual(V106)
Function
Parts
Date/Time Used to display the value of the RTC clock inside the PT in the set format.
Indirect Shape Modifying the specified communications addresses allows the specifying
rectangle, ellipse, location and size of the lines to draw the shape.
User Information Used to display the related information of the current login user in the table
form.
Multifunction Used to incorporate the Bit Button component and Command Button
component into one component, thus making the user realize the Bit Set and
Word Set operations through only one key.
Event Display Display the event information with [Event Setting] matching to the specified
trigger condition.
File List The File List is used to display the file information of the external memory.
This component is divided into three parts: the left part displays the
information on the folder under the current folder, the upper-right part
displays the information on the file under the current folder, and the lower-
right part displays the PT information on the selected project file.
Project
Database
Text Library Specify the necessary text strings in advance, thus preventing the label with
the same text from being input frequently.
Variable Table It is a useful address library, which prevents the inconvenience resulting from
repeated input of address.
Alarm Setting Specifying the message displayed in [Alarm] or [Alarm Display] and the bit
address and the trigger conditions applied to the trigger. If the bit address
registered to [Alarm Setting] matches the specified trigger condition, the
registered message will be displayed.
Event Setting Specifying the function operated with the message displayed in [Event] or
[Event Display], the communications addressed which should be the trigger,
and the trigger condition. If the bit address or word address registered to the
[Event Setting] are matched the specified trigger condition, the registered
function can be operated or the registered message can be displayed.
PLC Control Specify the communication address allocated to the specific functions as
follows. It is available to select among the screen switching, writing the data
(the current base screen) in the PLC, general PLC controlling, turning OFF
the back light, and turning ON the back light and others.
Screen
Type
Base Screen It is the general screen.
Common Sheet There is only 1 Common Sheet, which can be set to above or under the Base
Screen.
The maximum number of Base Screen ejected in 1 Common Sheet is up to
16.
Menu Screen There is only 1 Menu Screen, which will appear only after “Menu” is touched.
Sheet Screen Up to 3 Sheet Screens can be set for 1 Base Screen.
Pop-up Screen The types are “Tracking”, “Modal”, “Clipping” and “Fixed”.
It can be displayed normally or in the top layer.
The maximum number of Pop-up Screen ejected in 1 Base Screen is up to
16.
Direct Screen Up to 16 Direct Screens can be displayed simultaneously in 1 Base Screen.
It is controlled by the bit.
Indirect Screen Up to 16 Indirect Screens can be displayed simultaneously in 1 Base Screen.
It is controlled by word.
Screen Property Security level of the screen, screen attribute, background color, transparency
rate, width and color of frame, location to place screen, size of screen (width
and height), sheet screen allocated to screen (three screens at max.), type of
pop-up used as pop-up can be specified.
