3-7 Installing the Video Input Unit
3-39
z
Removing the Video Input Connector
1.
Unlock the BNC soc
ket on the camera’
s vi
deo output cable b
y twisting it counterclock-
wise while pushing it.
Twist c
ounterclock
wise
Push
2.
After unlocking the BNC soc
ket, pull it out.
Pull ou
t
92
94
