3-7 Installing the Video Input Unit
3-40
If the camera’
s video output cable uses
an RCA
plug, connect it to the video input
connector using a BNC-RCA
connector in the wa
y shown belo
w
.
Video input
connector
(BNC ty
pe)
BNC
-
RCA connec
tor (See note.)
RCA plug
Note
A BNC-RCA connector is provided with the M
onitor Cab
le (F150-VM) f
or OMR
ON Vision
Sensors.
It is not provided with
the
Video Input Unit (NS-CA001).
