Automatic Reset
Baud Rate
No
9600bps
(2/2)
Quit
WRT&
EXIT
MEMORY SW MENU
Page
85
Setting the Conditions of Communications with the PC/Host by Using the Memory Switches
Section 3-5
Each time the “Automatic Re-
set” touch switch is pressed, the
setting option “Yes” alternates
with “No”.
(The figure to the left shows the
NT20S-ST121-EV3 screen.)
To set and quit the menu, press the [WRT&EXIT] touch switch. To quit without set-
ting, press [Quit].
S “No”: If a communication error has occurred, corresponding error message is
displayed and the operation stops.
S “Yes”: If a communication error has occurred, corresponding error message will
not be displayed and the operation will be automatically reset.
To Next Page
