256
Method for Making the Cable for Connection to the Host
Appendix G
APPENDIX G
Method for Making the Cable for Connection to the Host
Explained below is the method for making the cable that connects the NT20S-ST121-EV3/ST128 with the PC.
Connect the wires to the connectors in accordance with the connector specification for each unit.
Parts Required
Two connectors, two connector covers and one cable are required to make up a connecting cable. One connector
and one connector cover is supplied with most PCs.
The parts supplied with each unit are indicated in the table below.
Name Model Delivered with Remarks
XM2A-0901
C series CQM1
CVM1/CV series CPU unit
CV500-LK201
9-pin, manufactured by OMRON
Connector
XM2A-2501
C500-LK203
C500-LK201
C200H-LK201
25-pin, manufactured by OMRON
DB-25P
C500-LK201-V1
C120-LK201-V1
25-pin, manufactured by JAE
XM2S-0911
C series CQM1
CVM1/CV series CPU unit
CV500-LK201
9-pin, manufactured by OMRON
Connector cover
XM2S-2511
C500-LK203
C500-LK201
C200H-LK201
25-pin, made by OMRON
DB-C2-J9
C500-LK201-V1
C120-LK201-V1
25-pin, made by JAE
When connecting the NT20S to a CjjH PC manufactured by OMRON, the connector and connector hood must
be prepared separately since they are not supplied with the CjjH.
The connector provided in the CPU unit of the CjjH is a 9-pin connector. For the connection, the following con-
nector and connector hood should be prepared.
S Connector : XM2A-0901 (9-pin, OMRON)
S Connector cover : XM2S-0911 (9-pin, OMRON)
Use the cable recommended by OMRON.
The recommended cables are indicated in the table below.
Name Model Remark
AWG28 5P
IFVV-SB
Multiconductor shielded cable (FUJIKURA, Ltd.)
Cable
CO-MA-VV-SB
5P 28AWG
Multiconductor shielded cable (HITACHI Cable, Ltd.)
To Next Page
