32
Connection to a PC by the Host Link
Section 2-4
2-4 Connection to a PC by the Host Link
Connect the NT20S-ST121-EV3 to an OMRON PC by the host link method.
To connect the NT20S to a PC using the host link method, the NT20S “Comm.
Type” memory switch must be set to “Host Link”. For details on the “Comm. Type”
setting, refer to “Selecting the Host Communication Method” (page 78).
2-4-1 Compatible PCs
Some models and series of OMRON PCs have the host link function built in. In the
C200HX/HG/HE series, there are CPU units that can support host link connec-
tions by installing an expansion communication board.
When making a connection, check the series and model of the PC to which the
connection is being made, and the type of host link unit that is installed. The follow-
ing is a list of the PCs that can be connected to the NT20S via a host link.
PC Series
Units with Built-in Host Link Function
CPU Units Connectable Usin
g
an
Connectable to
PC Series
Host Link Unit CPU Unit
CPU
Units
Connectable
Using
an
Expansion Communication Board
Connectable to
C20H/C28H/
C40H/C60H
CjjH
C120-LK201-V1
C120
C200H
C500 (F)
C1000H
C2000 (H)
C200H-LK201-V1 C200H
C200H-LK201-V1
C200HS-CPU21-E
C200HS-CPU23-E
C200HS-CPU31-E
C200HS-CPU33-E
C200HS
C200H-LK201-V1 C200HE-CPU42-E
C200HE-CPU32-E
C200HE-CPU42-E
C200HE
C series
C200H-LK201-V1
C200HG-CPU43-E
C200HG-CPU63-E
C200HG-CPU33-E
C200HG-CPU43-E
C200HG-CPU53-E
C200HG-CPU63-E
C200HG
C200H-LK201-V1
C200HX-CPU44-E
C200HX-CPU64-E
C200HX-CPU34-E
C200HX-CPU44-E
C200HX-CPU54-E
C200HX-CPU64-E
C200HX
C500-LK201-V1
C500-LK203
C500 (F)
C1000H (F)
C2000 (H)
CPM1-10CDR-j
CPM1-20CDR-j
CPM1-30CDR-j
CPM1
CQM1-CPU21-E
CQM1-CPU41-E
CQM1-CPU42-E
CQM1-CPU43-E
CQM1-CPU44-E
CQM1
