82
Setting the Conditions of Communications with the PC/Host by Using the Memory Switches
Section 3-5
3-5-4 Setting RS-232C Communication Conditions (NT20S-ST128)
When using an NT20S-ST128 (using the RS-232C interface for communication
with the host), set the following communication conditions.
S Data Bits
S Stop Bits
S Parity Check
S Flow Control
S Baud Rate
Set the same communication conditions at the host and the NT20S. You are rec-
ommended to set the highest baud rate that can be used by the host and NT20S.
The factory settings are as follows:
S Data Bits 8bits
S Stop Bits 2bits
S Parity Check Even
S Flow Control None
S Baud Rate 9600bps
Set the conditions of the communication with the Host by the menu operation from
the System Menu as mentioned below.
Select “Maintenance Mode”.
Select “Memory Switch”.
To Next Page
