Connection to a PC by the NT Link (1:1)
Section 2-5
2-5 Connection to a PC by the NT Link (1:1)
Connect the NT20S-ST121-EV3 to an OMRON PC by the NT link method.
To connect the NT20S to a PC by the NT link (1:1) method, the NT20S memory
switch for “host communication” must be set for the NT link. For the “host commu-
nication” setting, refer to “Selecting of the Host Communication Method”
(page 78).
2-5-1 Compatible PCs
Some models and series of OMRON PCs have the host link function built in. In the
C200HX/HG/HE series, there are CPU units that can support host link connec-
tions by installing an expansion communication board.
When making a connection, check the series and model of the PC to which the
connection is being made, and the type of host link unit that is installed. The follow-
ing is a list of the PCs that can be connected to the NT20S via a host link.
The compatible PCs are listed in the table below.
PC Series CPU Unit
CPU Units Connectable
Using an Expansion
Communication Board
Connectable to
CPM1-10CDR-j
CPM1-20CDR-j
CPM1-30CDR-j
CPM1
CQM1-CPU41-E
CQM1-CPU42-E
CQM1-CPU43-E
CQM1-CPU44-E
CQM1
C series
C200HS-CPU21-E
C200HS-CPU23-E
C200HS-CPU31-E
C200HS-CPU33-E
C200HS
C200HE-CPU42-E
C200HE-CPU32-E
C200HE-CPU42-E
C200HE
C200HG-CPU43-E
C200HG-CPU63-E
C200HG-CPU33-E
C200HG-CPU43-E
C200HG-CPU53-E
C200HG-CPU63-E
C200HG
C200HX-CPU44-E
C200HX-CPU64-E
C200HX-CPU34-E
C200HX-CPU44-E
C200HX-CPU54-E
C200HX-CPU64-E
C200HX
CV500-CPU01-EV1 CV500
CV series CV1000-CPU01-EV1 CV1000
CV2000-CPU01-EV1 CV2000
CVM1 series
CVM1-CPU01-EVj
CVM1-CPU11-EVj
CVM1-CPU21-EVj
CVM1
To Next Page
