Omron NT20S - Host Connections by RS-232 C

44
Connection to a PC by the Host Link
Section 2-4
S When using port A of C200HX/HG/HE
Channel # Writing Value Settings
DM6555 0001
Host link mode
Set the conditions with the contents of DM.
DM6556
0303
Data length: 7 bits, 2 stop bits, even parity,
baud rate: 9600 bps
DM6556
0304
Data length: 7 bits, 2 stop bits, even parity,
baud rate: 19200 bps
DM6558 0000 Unit No. 0
S When using port B of C200HX/HG/HE
Channel # Writing Value Settings
DM6550 0001
Host link mode
Set the conditions with the contents of DM.
DM6551
0303
Data length: 7 bits, 2 stop bits, even parity,
baud rate: 9600 bps
DM6551
0304
Data length: 7 bits, 2 stop bits, even parity,
baud rate: 19200 bps
DM6553 0000 Unit No. 0
S When using CPM1
Channel # Writing Value Settings
DM6650 0001
Host link mode
Set the conditions with the contents of DM.
DM6651
0303
Data length: 7 bits, 2 stop bits, even parity,
baud rate: 9600 bps
DM6651
0304
Data length: 7 bits, 2 stop bits, even parity,
baud rate: 19200 bps
DM6653 0000 Unit No. 0
