Omron NT20S User Manual

[ SYSTEM MENU ]
Quit
Transmit Mode
Maintenance Mode
[ MAINTENANCE MENU ]
Quit
PT Setting
I/O Check
DIP-SW Status
Init. Memory
Memory Switch
Comm. Type
Key Sound
Buzzer Sound
Host Link
OFF
Bk light Off
Tool Mode
OFF
None
NT20M
(1/2)
Quit
WRT&
EXIT
MEMORY SW MENU
Page
93
Various System Settings
Section 3-8
Types of the Buzzer Sounds The following buzzer sounds can be set.
S Continuous sound: The buzzer continues to sound.
S Intermittent sound: The buzzer sounds intermittently at constant intervals.
Reference: If both the continuous buzzer and the intermittent buzzer are instructed by the
Host, the continuous buzzer will sound.
Setting the Buzzer Use the memory switches to set whether or not the buzzer sounds when the buzz-
er sound has been instructed by the Host or with a screen attribute or when an
error has occurred.
The factory setting is “ON”, which means that the buzzer will sound when a com-
mand is received from the host, when a screen for which the buzzer attribute is set
is displayed, and when errors occur.
Set the buzzer sound by the menu operation from the System Menu as mentioned
below.
Select “Maintenance Mode”.
Select “Memory Switch”.
Repeatedly pressing the “Buzz-
er Sound” touch switch cycles
through the setting options
“ON”, “ERR ON”, and “OFF”, in
that order.
(The figure to the left shows the
NT20S-ST121-EV3 screen.)
