Stop Bits
Parity Check
Flow Control
1bit
Even
Baud Rate
LMP Bit Control
RS/CS
19200bps
Enable
Data Bits
8bits
Quit
WRT&
EXIT
Page
98
Various System Settings
Section 3-8
Each time the “LMP Bit Control”
touch switch is pressed, the set-
ting option “Enable” alternates
with “Disable”.
To set and quit the menu, press the [WRT&EXIT] touch switch. To quit without set-
ting, press [Quit].
S When “Disable” is set, the control of lamp display statuses by bits is not possible.
The lamps numbered 0 to 31 can be controlled only by specifying lamp numbers.
S When “Enable” is set, lamp control by bits is possible. This means that the lamps
numbered 0 to 31 can be controlled by specifying either lamp numbers or bits.
However, it is not possible to make “lit”/“flashing” status selections by specifying
lamp numbers: the selection made when the screen data was created remains
effective.
