Omron NT20S - Memory Tables

Line 1
Touch switch #11
RUN
Touch switch #10
STOP
186
Lamps, Touch Switches, Numeral Setting
Section 5-3
Example of determination of touch switch status
This example uses the touch switches as normal switches (bits) in order to use the
NT20S as an operating panel.
S Support Tool Settings
Make the following settings using the support tool.
Touch switch #10:
Function “Notify Bit”
Display attribute “Light”
Control bit CH05000 (Run flag) ... Guide message: “RUN”
Notify bit CH 06000
Touch switch #11:
Function “Notify Bit”
Display attribute “Light”
Control bit CH 05000 (Stop flag) ... Guide message: “STOP”
Notify bit CH 06001
Data registered for the screen: touch switch #10, touch switch #11
