Bit
Parameter
210
Lamps, Touch Switches, Numeral Setting
Section 6-4
Lamp and Touch Switch Display (Bit Specification)
Format
1B
[ESC]
4B
K
m0
1
**
m0
2
**
m1
2
**
m2
1
**
m2
2
**
m3
1
**
m1
1
**
m3
2
**
[CR]
0D
m0 to m3: Specification of lamps and touch switches (2-digit hexadecimal)
The relationship between the lamp and touch switch number and an
expression of m0 to m3 in bits is given in the following table.
mx
1
mx
2
7 6 5 4 3 2 1 0
m0 07 06 05 04 03 02 01 00
m1 15 14 13 12 11 10 09 08
m2 23 22 21 20 19 18 17 16
m3 31 30 29 28 27 26 25 24
mx1: Higher 4 bits of mx (x: 0 to 3)
mx2: Lower 4 bits of mx
Bit ON: The lamp or touch switch is turned on (or caused to flash).
Bit OFF: The lamp or touch switch is turned off.
Example To turn on lamps and touch switches with the numbers 1, 5, 6, 7, and 26
m0
1
m0
2
m1
1
m1
2
m2
1
m2
2
m3
1
m3
2
=E200004
Description
S Changes the display status of the lamps or touch switches.
S Whether the lamp or touch switch which corresponds to the specified bit is
turned on or flashes is determined by the setting made using the support tool.
S This command can be used only when the setting for the “LMP Bit Control”
memory switch is “Enable”.
Lamp and Touch Switch Display (Number Specification)
Format
1B
[ESC]
n
1
**
n
2
**
m
1
**
51
Q
m
1
: Display status
0 (30
H
): Not lit (normal display)
1 (31
H
): Lit
2 (32
H
): Flashing inverse
3 (33
H
): All not lit
n
1
n
2
: Lamp or touch switch # (2-digit hexadecimal)
000 to FF
H
(0 to 255)
