Bit Meaning
7 This bit indicates whether a major fault level Controller error has occurred.
TRUE: A major fault level Controller error has occurred.
F
ALSE: A major fault level Controller error has not occurred.
6 This bit indicates whether a partial fault level Controller error has occurred.
TRUE: A partial fault level Controller error has occurred.
F
ALSE: A partial fault level Controller error has not occurred.
5 This bit indicates whether a minor fault level Controller error has occurred.
TRUE: A minor fault level Controller error has occurred.
F
ALSE: A minor fault level Controller error has not occurred.
4 This bit indicates whether an observation level Controller error has occurred.
TRUE: An observation level Controller error has occurred.
F
ALSE: An observation level Controller error has not occurred.
0 to 3 Reserved.
Note Bits 14 and 15 are never TRUE for the built-in EtherNet/IP port.

Functional Classification: EtherNet/IP Communications Status
Variable name Meaning Function Data type
Range of
values
Reference
_EIP_EtnOnlineSta Online NX-series CPU Units: Indicates that the
built-in EtherNet/IP port's communica-
tions can be used via the communica-
tions port 1 (that is, the link is ON, IP ad-
dress is defined, and there are no errors.)
TRUE: The built-in EtherNet/IP port’
s
communications can be used.
FALSE: The built-in EtherNet/IP port’s
communications is disabled due to an er-
ror in initial processing, restart process-
ing, or link OFF status.
NJ-series CPU Units: Indicates that the
built-in EtherNet/IP port's communica-
tions can be used via the communica-
tions port (that is, the link is ON and IP
address is defined, and there are no er-
rors.)
TRUE: The built-in EtherNet/IP port’s
communications can be used.
FALSE: The built-in EtherNet/IP port’s
communications is disabled due to an er-
ror in initial processing, restart process-
ing, or link OFF status.
BOOL TRUE or
FALSE
page 3-51
_EIP1_EtnOnlineSta Port1 Online Indicates that the built-in EtherNet/IP
port's communications can be used via
the communications port 1 (that is, the
link is ON, IP address is defined, and
there are no errors.)
TRUE: The built-in EtherNet/IP port’
s
communications can be used.
FALSE: The built-in EtherNet/IP port’s
communications is disabled due to an er-
ror in initial processing, restart process-
ing, or link OFF status.
Note You can use this system-de-
fined variable only for NX-ser-
ies CPU Units.
BOOL TRUE or
FALSE
page 3-52
3 System-defined Variables Related to the Built-in EtherNet/IP Port
3-22
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
