Variable name _EIP2_TagAdrErr
Meaning CIP Communications2 Tag Name Resolution
Error
Global/local Global
Function Indicates that the tag resolution for CIP communications 2 failed (i.e., the address could not be identified from the
tag name).
TRUE: T
ag resolution failed (i.e., the address could not be identified from the tag name). The following causes are
possible.
• The size of the network variable is different from the tag settings.
• The I/O direction that is set in the tag data link settings does not agree with the I/O direction of the variable in
the CPU Unit.
• There is no network variable in the CPU Unit that corresponds to the tag setting.
FALSE: Other than the above.
Note You can use this system-defined variable only for the NX701 CPU Units and NX102 CPU Units.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name _EIP_MultiSwONErr
Meaning Multiple Switches ON Error Global/local Global
Function NX-series CPU Units: Indicates that more than one switch turned ON at the same time in CIP communications 1.
TRUE: More than one data link start/stop switch changed to TRUE at the same time.
F
ALSE: Other than the above.
NJ-series CPU Units: Indicates that more than one switch turned ON at the same time
TRUE: More than one data link start/stop switch changed to TRUE at the same time.
FALSE: Other than the above.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name _EIP1_MultiSwONErr
Meaning CIP Communications1 Multiple Switches ON
Error
Global/local Global
Function Indicates that more than one switch turned ON at the same time in CIP communications 1.
TRUE: More than one data link start/stop switch changed to TRUE at the same time.
F
ALSE: Other than the above.
Note You can use this system-defined variable only for NX-series CPU Units.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name _EIP2_MultiSwONErr
Meaning CIP Communications2 Multiple Switches ON
Error
Global/local Global
Function Indicates that more than one switch turned ON at the same time in CIP communications 2.
TRUE: More than one data link start/stop switch changed to TRUE at the same time.
F
ALSE: Other than the above.
Note You can use this system-defined variable only for the NX701 CPU Units and NX102 CPU Units.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
---
3 System-defined Variables Related to the Built-in EtherNet/IP Port
3-50
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
