Creating and Adding Tags
1 Click the Edit T
ags Button.
The Edit Tags Dialog Box is displayed. Register input (consume) tags and output (produce)
tags separately.
2 Click the In - Consume
Tab, and then click the New Button.
The Edit Tag Dialog Box is displayed.
7 Tag Data Link Functions
7-25
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
7-2 Setting Tag Data Links
7
7-2-4 Creating Tags and Tag Sets
To Next Page
