Uploading from All Devices in the Network
1 Connect the Network Configurator online, and then select Upload from the Network Menu.
2 The following dialog box is displayed.
• Clicking the Y
es Button:
The tag data link parameters in the current project are uploaded.
• Clicking the No Button:
You open a new project to upload the tag data link parameters. The current project is closed.
• Clicking the Cancel Button:
The upload operation is canceled. The upload is not performed.
3 If you click the Y
es Button in step 2, the following dialog box is displayed.
• Clicking the Y
es Button:
Parameters are uploaded only from the devices registered in the Network Configuration
Pane. Parameters are not uploaded from devices that are not registered in the Network Con-
figuration Pane.
• Clicking the No Button:
Performing a Batch Upload over the Network
Parameters are uploaded from all devices on the network.
The current Network Configuration Information will be lost.
The following dialog box will be displayed. Select the devices for which to upload parameters
and click the OK Button.
7 Tag Data Link Functions
7-62
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
