• Clicking the Cancel Button:
The upload operation is canceled. The upload is not performed.
4 If you click the No Button in step 2, the following dialog box is displayed.
Select the devices for which to upload parameters and click the OK Button.
Uploading Individually from Particular Devices
1 Connect the Network Configurator to the network.
Select the icon of the EtherNet/IP Unit from which you want to upload parameters. T
o select
multiple nodes, press and hold the Shift Key or the Ctrl Key while you select additional icons.
(In the following example, 2 nodes are selected: 192.168.250.1 and 192.168.250.2.)
Right-click the icon to display the pop-up menu, and select Parameter - Upload.
7 Tag Data Link Functions
7-63
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
7-2 Setting Tag Data Links
7
7-2-10 Uploading Tag Data Link Parameters
