Response Data Format
When the processing is successful
Parameter name Data type Description
Reply Service USINT Get current user error service response: BE hex
Reserved USINT Reserved: 00 hex
General Status USINT Code indicating normal: 00 hex
Size of Additional Status USINT Size of Additional Status: 00 hex
Error update count UINT Total count value of errors
Record size UINT Size of one record (Byte):0060 hex
Number of registered record UINT Number of registered records
Number of readout record UINT Number of readout records
User error record[0]
to
User error record[8]
Array of struct User
error record
User-defined error array
Stores data for the "Number of readout record
" from
index 0 of the User error record. The remaining ele-
ments of the User error record array are not includ-
ed in the response data.
Example: When the "Number of readout record" is 3
and the response data includes the User error re-
cord array [0-2], the User error record array [3-8] is
not included in the response data.
For details of the specifications of the structure, re-
fer to User Error Record Structure.
When the processing failed
Parameter name Data type Description
Reply Service USINT Get current user error service response: BE hex
Reserved USINT Reserved: 00 hex
General Status USINT Current error code defined by CIP
Size of Additional Status USINT
Size of Additional Status: 00 hex or 01 hex
*1
Additional Status UINT
Additional Status
*2
*1. When the General Status of the response code is 1F hex (Vendor specific error), becomes 01 hex.
*2. This is stored only when the Size of Additional Status is 01 hex.

User Error Record Structure
Parameter name Data type Description
Index UDINT User-defined error index number
This number is assigned when system event logs
and access event logs are registered.
Event occurred time ULINT Error occurred time
Event source UINT Error source
Event priority UINT Error level
Event code UDINT Event code
Event priority details UINT Error level details
Reserved UINT Reserved
Additional information[0]
to
Additional information[39]
Array of BYTE Attached information (system information) of event.
8 CIP Message Communications
8-70
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
