Omron NX102-12 Series User Manual


NX1P2 CPU Unit
Indicators
IN
OUT
POWER
R
UN
ERROR
BUSY
SD PWR
SD BUSY
NET RUN
NET ERR
LINK/ACT
NETRUN
NET ERR
LINK/ACT
PORT1 EtherNet/IP
PORT2 EtherCAT
SW SETTING
Built-in EtherNet/IP port
PORT1 EtherNet/IP
PORT2 EtherCAT
MAC Address Notation
A MAC address is uniquely allocated to each device connected to the Ethernet network. The MAC
address of the built-in EtherNet/IP port is represented in 12-digit hexadecimal format and listed in
the place of the Unit as shown below
.
PORT1 : ££££££££££££
PORT
2 : ££££££££££££
Ver.1.££ HW Rev. £
LOT No. DDMYY£ xxxx
MAC address of built-in EtherNet/IP port
1 Introduction
1-15
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
1-3 Built-in EtherNet/IP Port
1
1-3-2 Part Names and Functions
