NJ-series CPU Unit
Indicators
Buil
t-in EtherCAT port
Built-in EtherNet/IP port
USB port
MAC Address Notation
A MAC address is uniquely allocated to each device connected to the Ethernet network. The MAC
address of the built-in EtherNet/IP port is represented in 12-digit hexadecimal format and listed in
the two places of the Unit as shown below
.
MAC address (12 digits)
NJ501-XXXX
PORT1 : XXXXXXXXXXXX
PORT2 : XXXXXXXXXXXX
XXXXXXX XXXX
Ver. XXX
PORT 1
X
XXXXX
XXXXXX
Upper 6 digits of MAC address
Lower 6 digits of MAC address
