Connection status

Source of error

Handling

General

Status

(hex)

Additional

Status

(hex)

Configuration

01 0205 Error code returned from target:

There was a parameter error in the

frame used to open the connection.

This error does

not occur

Depends on

the target's

specifications.

(Contact the

target device's

manufacturer.)

Depends on

the originator's

specifications.

(Contact the

originator devi-

ce's manufac-

turer.)

01 0301 Error code generated by originator or re-

turned from target:

otal number of tag sets that are set to

the product was exceeded.

Check the total

number of the

tag sets that

are set to the

product and set

the tag sets so

that the total

number does

not exceed the

maximum of

the allowable

number.

Check the total

number of the

tag sets that

are set to the

product and set

the tag sets so

that the total

number does

not exceed the

maximum of

the allowable

number.

Check the total

number of the

tag sets that

are set to the

product and set

the tag sets so

that the total

number does

not exceed the

maximum of

the allowable

number.

01 0302 Error code generated by originator or re-

turned from target:

The tag data link's allowable bandwidth

(pps) was exceeded.

Check the con-

nection set-

tings (number

of connections

and RPI) at the

originator and

target.

Check the tar-

get's connec-

tion settings

(number of

connections

and RPI).

Check the con-

nection set-

tings (number

of connections

and RPI) at the

originator and

target.

Check the con-

nection settings

(number of

connections

and RPI) at the

originator and

target.

01 0311 Error code returned from target:

There was a parameter error in the

frame used to open the connection.

This error does

not occur

Depends on

the target's

specifications.

(Contact the

target device's

manufacturer.)

Depends on

the originator's

specifications.

(Contact the

originator devi-

ce's manufac-

turer.)

01 0312 Error code returned from target:

There was a parameter error in the

frame used to open the connection.

This error does

not occur

Depends on

the target's

specifications.

(Contact the

target device's

manufacturer.)

Depends on

the originator's

specifications.

(Contact the

originator devi-

ce's manufac-

turer.)

16 Troubleshooting

16-15

NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)

16-2 Checking Status with the Network Configurator

16-2-2 Connection Status Codes and Troubleshooting
