Variable name Meaning Function Data type
Range of
values
Reference
_EIP1_CipErr CIP Communica-
tions1 Error
This is the error status variable for CIP
communications 1.
It represents the collective status of the
following error flags.
• _EIP1_IdentityErr (CIP Communica-
tions1 Identity Error)
• _EIP1_TDLinkCfgErr (CIP Communi-
cations1 T
ag Data Link Setting Error)
• _EIP1_TDLinkOpnErr (CIP Communi-
cations1 Tag Data Link Connection
Failed)
• _EIP1_TDLinkErr (CIP Communica-
tions1 Tag Data Link Communications
Error)
• _EIP1_TagAdrErr (CIP Communica-
tions1 Tag Name Resolution Error)
• _EIP1_MultiSwONErr (CIP Communi-
cations1 Multiple Switches ON Error)
Note If a Tag Name Resolution Error
occurs, it is recorded in the
event log and this variable
changes to TRUE. Refer to in-
formation on the meanings of
the error status bits at the end
of this appendix for details.
Note You can use this system-de-
fined variable only for NX-ser-
ies CPU Units.
WORD 16#0000 to
16#00F0
page 3-39
_EIP2_CipErr CIP Communica-
tions2 Error
This is the error status variable for CIP
communications 2.
It represents the collective status of the
following error flags.
• _EIP2_IdentityErr (CIP Communica-
tions2 Identity Error)
• _EIP2_TDLinkCfgErr (CIP Communi-
cations2 T
ag Data Link Setting Error)
• _EIP2_TDLinkOpnErr (CIP Communi-
cations2 Tag Data Link Connection
Failed)
• _EIP2_TDLinkErr (CIP Communica-
tions2 Tag Data Link Communications
Error)
• _EIP2_TagAdrErr (CIP Communica-
tions2 Tag Name Resolution Error)
• _EIP2_MultiSwONErr (CIP Communi-
cations2 Multiple Switches ON Error)
Note If a Tag Name Resolution Error
occurs, it is recorded in the
event log and this variable
changes to TRUE. Refer to in-
formation on the meanings of
the error status bits at the end
of this appendix for details.
Note You can use this system-de-
fined variable only for the
NX701 CPU Units and NX102
CPU Units.
WORD 16#0000 to
16#00F0
page 3-39
3 System-defined Variables Related to the Built-in EtherNet/IP Port
3-8
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
