Variable name Meaning Function Data type
Range of
values
Reference
_EIP2_LanHwErr Port2 Communica-
tions Controller Error
Indicates that a communications control-
ler failure occurred on the communica-
tions port 2.
TRUE: Failure
F
ALSE: Normal
Note You can use this system-de-
fined variable only for the
NX701 CPU Units and NX102
CPU Units.
BOOL TRUE or
FALSE
page 3-41
_EIP_EtnCfgErr Basic Ethernet Set-
ting Error
NX-series CPU Units: Indicates that the
Ethernet communications speed setting
(Speed/Duplex) for the communications
port 1 is incorrect. Or
, a read operation
failed.
TRUE: Setting incorrect or read failed.
FALSE: Normal
NJ-series CPU Units: Indicates that the
Ethernet communications speed setting
(Speed/Duplex) is incorrect. Or, a read
operation failed.
TRUE: Setting incorrect or read failed.
FALSE: Normal
BOOL TRUE or
FALSE
page 3-41
_EIP1_EtnCfgErr Port1 Basic Ethernet
Setting Error
Indicates that the Ethernet communica-
tions speed setting (Speed/Duplex) for
the communications port 1 is incorrect.
Or
, a read operation failed.
TRUE: Setting incorrect or read failed.
FALSE: Normal
Note You can use this system-de-
fined variable only for NX-ser-
ies CPU Units.
BOOL TRUE or
FALSE
page 3-41
_EIP2_EtnCfgErr Port2 Basic Ethernet
Setting Error
Indicates that the Ethernet communica-
tions speed setting (Speed/Duplex) for
the communications port 2 is incorrect.
Or
, a read operation failed.
TRUE: Setting incorrect or read failed.
FALSE: Normal
Note You can use this system-de-
fined variable only for the
NX701 CPU Units and NX102
CPU Units.
BOOL TRUE or
FALSE
page 3-42
3 System-defined Variables Related to the Built-in EtherNet/IP Port
3-10
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
