Functions Shared by all Units Section 2-3
2-3-5 Unit Comments
Function Overview The user can assign and record a name or comment for every Unit (up to 32
characters). The network Programming Device can be used to read and write
these Unit names (comments).
Setting with a
Programming Device
This example shows how to use the DeviceNet Configurator (version 2.43 or
higher) to set the Unit Comments.
1,2,3... 1. Open the Network Configuration Window and double-click the desired
Slice I/O Terminal’s icon or right-click the icon and select Parameters -
Edit to display the Edit Device Parameters Window.
2. Click the I/O Module Tab.
Slice I/O Unit
Recorded in Unit
Unit comment
Set a Unit name with th
Programming Device.
To Next Page
