59
Parameters
Options Functions/Meanings
Fast feed speed (mm/s) Numerical Sets the speed of the laser head when not ring laser beams.
Fast feed acc (mm/s²) Numerical Sets the acceleration of the laser head when not ring laser beams.
Corner spd (mm/s)* Numerical Sets the speed of the laser head when making sharp turns.
Corner acc (mm/s²) Numerical Sets the acceleration of laser head when making sharp turns.
Cutting acc (mm/s²) Numerical Sets the acceleration of the beaming laser head.
Fast feed delay (ms)* Numerical Sets the time the laser head rests for after travelling without beaming.
* If your engraving design has a lot of serrated or zigzag patterns, set the parameter at a value that best suits your
design. Practice on scrap materials rst.
* When set to zero, the laser head doesn’t rest after traveling without beaming. When set to a certain value, the
laser head slows down upon the completion of traveling without beaming and rest for the set milliseconds.
Parameters
Options Functions/Meanings
Cut jerk (0–200%) Numerical Sets the speed of the laser head when beaming in percentages.
Fast feed jerk (0–200%) Numerical
Sets the time the laser head rests for after travelling without
beaming in percentages.
Corner jerk (0–200%) Numerical
Sets the speed of the laser head when making sharp turns in
percentages.
X Backlash (mm) Numerical Does not need adjusting.
Y Backlash (mm) Numerical Does not need adjusting.
