5.1 Channel System + ZONE SPEAKER
MAIN ROOM: This is a basic 5.1 Channel
System. For details of the speaker layout,
refer to "Speaker Installation" ( p12).
ZONE 2: You can enjoy 2-ch audio in the
separate room (ZONE 2) while performing
5.1-ch playback in the main room (where
this unit is located). The same source
can be played back in the main room and
ZONE 2 simultaneously. Also, dierent
sources can be played back in both
rooms.
Setup
• In this case, settings are required.
Refer to "Menu operations" ( p60)
and set "2. Manual SP Setup"
( p61) - "a. Speaker System" to
"ZONE 2" after all connections are
completed.
MAIN ROOM
12
45
3
6
ZONE 2
To output audio from an externally
connected AV component to ZONE 2, use
an analog audio cable for connection.
( p28)
*
