Din 912 / ISO
4762 /
ISO 14579 /
ISO 14580 /
ASME B18.3
Hex Cylinder
ISO 14581 /
ASME B18.6
HEX
Counter
sunk /
ASME
B18.6.3 Torx
Counter
sunk
DIN 7985A /
ASME B18.6.3
Cross recessed
Button head /
ASME B18.6.3
Torx Button
head
When this is achieved, remove the screw and push in the screw fix (only Din 912, ISO 4762,
ISO 14579, ISO 14580 and ASME B18.3 HEX Cylinder screw types).
The final setup of the Screw-bit System with the screw in place should look like picture below.
